LINEAR SHAKING BATH
A general-purpose series of thermostatically controlled orbital and linear shaking water baths designed for indoor laboratory use by a professional user.
Applications
- Clinical/healthcare - thawing/mixing samples
- Pharmaceutical - heating and mixing samples
- Science education in schools/universities - practical science demonstration and experimentation
- Industrial - QC testing, sample preparation
Grant quality and design combined with the temperature stability and functions you need in a linear shaking bath for your laboratory.
- Temperature range ambient +5ºC to 99ºC operation
- Stability: ±0.1ºC
- Choice of two models - 12 and 18 litres
- Universal tray and polycarbonate lid included as standard
- Robust magnetically coupled shaking mechanism
- Two programmable temperature and shaking presets
- Drain tap for convenient emptying
SHARE
Enquiry Now
A general-purpose series of thermostatically controlled orbital and linear shaking water baths designed for indoor laboratory use by a professional user.
Applications
- Clinical/healthcare - thawing/mixing samples
- Pharmaceutical - heating and mixing samples
- Science education in schools/universities - practical science demonstration and experimentation
- Industrial - QC testing, sample preparation
Grant quality and design combined with the temperature stability and functions you need in a linear shaking bath for your laboratory.
- Temperature range ambient +5ºC to 99ºC operation
- Stability: ±0.1ºC
- Choice of two models - 12 and 18 litres
- Universal tray and polycarbonate lid included as standard
- Robust magnetically coupled shaking mechanism
- Two programmable temperature and shaking presets
- Drain tap for convenient emptying
| LSB12 | LSB18 | |
| Dimensions (h x d x w) | 425 x 385 x 360mm | 425 x 565 x 335mm |
| Capacity | 12L | 18L |
| Temperature range | Ambient +5 to 99°C | Ambient +5 to 99°C |
| Stability (DIN 12876-3) @70ºC | 0.1°C | 0.1°C |
| Uniformity (DIN 12876-3) @70ºC | 0.1 ±ºC | 0.1 ±ºC |
| Working area (d x w) | 240 x 235mm | 420 x 235mm |
| Mix/max liquid level | 60/93mm | 60/93mm |
| Linear shaking speed | 20 to 200rpm (depending on load) | 20 to 200rpm (depending on load) |
| Shaking speed display resolution | 1rpm | 1rpm |
| Linear shaking stroke length | 20mm | 20mm |
| Display | LED | LED |
| Timer | 1 to 999 minutes | 1 to 999 minutes |
| Drain tap | • | • |
| Safety | Over temperature protection/low liquid level cut-out | Over temperature protection/low liquid level cut-out |
| Heater power - 230V | 800W | 1400W |
| Heater power - 120V | 800W | 1050W |
| Supply voltage | 120 or 230V | 120 or 230V |
| Weight | 8.9kg | 11.2kg |
